Installation Notices for the M.2 and SATA Connectors:

The availability of the SATA connectors may be affected by the type of device installed in the M.2 sockets.

The M2C_SB connector shares bandwidth with the SATA3 4, 5 connectors. Refer to the following tables

for details.

• M2B_SB:

SATA3 0 SATA3 1 SATA3 2 SATA3 3 SATA3 4 SATA3 5

M.2 PCIe SSD

a a a a a a

No M.2 SSD Installed

M.2 SATA SSD

a a a a a a

M.2 PCIe SSD

a a a a r r

No M.2 SSD Installed

a a a a a a

a: Available, r: Not available

Connector

• M2A_CPU:

SATA3 0 SATA3 1 SATA3 2 SATA3 3 SATA3 4 SATA3 5

a: Available, r: Not available

Connector

Type of

M.2 SSD

Type of

M.2 SSD
