1-2 Product Specications
CPU AMD Socket AM4, support for:
AMD Ryzen
™
5000 Series Processors/
AMD Ryzen
™
5000 G-Series Processors/
AMD Ryzen
™
4000 G-Series Processors/
AMD Ryzen
™
3000 Series Processors/
AMD Ryzen
™
3000 G-Series Processors/
AMD Ryzen
™
2000 Series Processors/
AMD Ryzen
™
2000 G-Series Processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset AMD X570
Memory
AMD Ryzen
™
5000 Series/5000 G-Series/4000 G-Series/3000 Series Processors:
- Support for DDR4 3200/2933/2667/2400/2133 MHz memory modules
AMD Ryzen
™
3000 G-Series/2000 Series/2000 G-Series Processors:
- Support for DDR4 2933/2667/2400/2133 MHz memory modules
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)
of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
(Note 1)
Integrated Graphics Processor:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.1 version, HDCP 2.3, and HDR.
Maximum shared memory of 16 GB
Audio Realtek
®
ALC1220-VB Audio CODEC
* The back panel line out jack supports DSD audio.
Support for DTS:X
®
Ultra
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN Intel
®
2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Wireless
Communication
Module
Intel
®
Wi-Fi 6 AX200 (For PCB rev. 1.0)
- WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz Dual-Band
- BLUETOOTH 5.2
- Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
AMD Wi-Fi 6E RZ608 (MT7921K) (For PCB rev. 1.1)
- WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.2
- Support for 11ax 80MHz wireless standard and up to 1.2 Gbps data rate
(Actual data rate may vary depending on environment and equipment.)
(Note 1) For AMD Ryzen
™
5000 G-Series/4000 G-Series/3000 G-Series/2000 G-Series Processors only.
