Center/Subwoofer Speaker Out (Orange)
Use this audio jack to connect center/subwoofer speakers.
Rear Speaker Out (Black)
Use this audio jack to connect rear speakers.
Side Speaker Out (Gray)
Use this audio jack to connect side speakers.
Line In (Blue)
The line in jack. Use this audio jack for line in devices such as an optical drive, walkman, etc.
Line Out/Front Speaker Out (Green)
The line out jack.
Mic In (Pink)
The Mic in jack.
AudioJackCongurations:
Jack
Headphone/
2-channel
4-channel 5.1-channel 7.1-channel
Center/Subwoofer Speaker Out
a a
RearSpeakerOut
a a a
Side Speaker Out
a
Line In
Line Out/Front Speaker Out
a a a a
Mic In
You can change the functionality of an audio jack using the audio software.
PleasevisitGIGABYTE'swebsitefordetailsonconguringtheaudiosoftware.
- 12 -
