1-2 ProductSpecications
CPU AMD Socket AM4, support for:
AMDRyzen
™
5000 Series Processors/
AMDRyzen
™
4000 G-Series Processors/
AMDRyzen
™
3000 Series Processors/
AMDRyzen
™
3000 G-Series Processors/
AMDRyzen
™
2000 Series Processors/
AMDRyzen
™
2000 G-Series Processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset
AMD X570
Memory AMDRyzen
™
5000SeriesProcessors/AMDRyzen
™
4000 G-Series Processors/
AMDRyzen
™
3000 Series Processors:
- SupportforDDR43200/2933/2667/2400/2133MHzmemorymodules
AMDRyzen
™
3000G-SeriesProcessors/AMDRyzen
™
2000 Series Processors/
AMDRyzen
™
2000 G-Series Processors:
- SupportforDDR42933/2667/2400/2133MHzmemorymodules
4xDDR4DIMMsocketssupportingupto128GB(32GBsingleDIMMcapacity)
of system memory
Dual channel memory architecture
SupportforECCUn-bufferedDIMM1Rx8/2Rx8memorymodules
Supportfornon-ECCUn-bufferedDIMM1Rx8/2Rx8/1Rx16memorymodules
SupportforExtremeMemoryProle(XMP)memorymodules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
(Note1)
Integrated Graphics Processor:
- 1xHDMIport,supportingamaximumresolutionof4096x2160@60Hz
* SupportforHDMI2.1version,HDCP2.3,andHDR.
Maximum shared memory of 16 GB
Audio Realtek
®
Audio CODEC
HighDenitionAudio
2/4/5.1/7.1-channel
LAN Realtek
®
2.5GbELANchip(2.5Gbps/1Gbps/100Mbps)
Expansion Slots 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
- AMDRyzen
™
5000SeriesProcessors/AMDRyzen
™
3000 Series Processors
support PCIe 4.0 x16 mode
- AMDRyzen
™
4000G-SeriesProcessors/AMDRyzen
™
2000 Series
Processors support PCIe 3.0 x16 mode
- AMDRyzen
™
3000G-SeriesProcessors/AMDRyzen
™
2000 G-Series
Processors support PCIe 3.0 x8 mode
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot (PCIEX2), integrated in the Chipset:
- Supporting PCIe 4.0
(Note2)
/3.0 x2 mode
* The PCIEX2 slot shares bandwidth with the SATA3 4, 5 connectors. The SATA3 4, 5
connectors will become unavailable when a device is installed in the PCIEX2 slot.
2 x PCI Express x1 slots (PCIEX1_1/PCIEX1_2), integrated in the Chipset:
- Supporting PCIe 4.0
(Note2)
/3.0
(Note1) ForAMDRyzen
™
4000G-SeriesProcessors/AMDRyzen
™
3000G-SeriesProcessors/AMDRyzen
™
2000 G-Series Processors only.
(Note2) ForAMDRyzen
™
5000SeriesProcessors/AMDRyzen
™
3000 Series Processors only.
