Storage Interface 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,
M key, type 2242/2260/2280/22110 SSDs:
- AMDRyzen
™
5000SeriesProcessors/AMDRyzen
™
3000 Series Processors
support SATA and PCIe 4.0 x4/x2 SSDs
- AMDRyzen
™
4000 G-SeriesProcessors/AMD Ryzen
™
3000 G-Series
Processors/AMD Ryzen
™
2000 Series Processors/AMD Ryzen
™
2000 G-Series Processors support SATA and PCIe 3.0 x4/x2 SSDs
1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3,
M key, type 2242/2260/2280/22110 SSDs:
- Supporting PCIe 4.0
(Note2)
/3.0 x4/x2 SSDs
1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3,
M key, type 2242/2260/2280/22110 SSDs:
- Supporting SATA and PCIe 4.0
(Note2)
/3.0 x4/x2 SSDs
6 x SATA 6Gb/s connectors, integrated in the Chipset:
- SupportforRAID0,RAID1,andRAID10
USB CPU:
- 4 x USB 3.2 Gen 1 ports on the back panel
Chipset:
- 2 x USB Type-C
®
ports, with USB 3.2 Gen 2 support (1 port on the back
panel, 1 port available through the internal USB header)
- 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
the internal USB headers)
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
1 x water cooling CPU fan header
3 x system fan headers
1 x system fan/water cooling pump header
2 x addressable LED strip headers
2xRGBLEDstripheaders
1xCPUcoolerLEDstrip/RGBLEDstripheader
3 x M.2 Socket 3 connectors
6 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB Type-C
®
header, with USB 3.2 Gen 2 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S
module only)
1 x Clear CMOS jumper
- 7 -
