- 4 -
B550 UD AC Motherboard Layout
Box Contents
5 B550 UD AC motherboard 5 User's Manual
5 Two antennas 5 Two SATA cables
5 I/O Shield 5 M.2 screws
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Temperature sensor
USB20_1
USB20_2
M2_WIFI
HDMI
U32C
U32G2
QFLASH_PLUS
QFLED
U32_LAN
ATX
AUDIO
DDR4_A1
DDR4_A2
DDR4_B1
DDR4_B2
ATX_12V
AMD B550
CLR_CMOS
M_BIOS
PCIEX1_3
PCIEX1_1
PCIEX1_2
PCIEX1_4
PCIEX16
SYS_FAN2
CODEC
B550 UD AC
F_USB2 F_U32
F_U32C
SYS_FAN3
TPM F_USB1 F_PANEL
D_LED2 LED_C2
D_LED1
LED_C1
F_AUDIO
SYS_FAN1
LED_CPU
CPU_FAN
iTE
®
Super I/O
M2A_CPU
4280 60110
M2B_SB
4280 60110
SATA3
1 0
SATA3
2 3
BAT
Realtek
®
GbE LAN
Socket AM4
CPU_OPT
USB 2.0 Hub
