1-2 ProductSpecications
CPU AMD Socket AM4, support for:
AMD Ryzen
™
5000 G-Series Processors/
AMD Ryzen
™
5000 Series Processors/
AMD Ryzen
™
4000 G-Series Processors/
AMD Ryzen
™
3000 Series Processors
(Go to GIGABYTE's website for the latest CPU support list.)
Chipset AMD B550
Memory 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)
of system memory
Support for DDR4 3200/2933/2667/2400/2133 MT/s memory modules
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Integrated in the AMD Ryzen
™
5000 G-Series/4000 G-Series Processors:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.1 version, HDCP 2.3, and HDR.
Maximum shared memory of 16 GB
Audio Realtek
®
Audio CODEC
High Denition Audio
2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To congure
7.1-channel audio, access the audio software for audio settings.
LAN Realtek
®
GbE LAN chip (1 Gbps/100 Mbps)
Wireless
Communication
Module
Realtek
®
Wi-Fi RTL8821CE
- WIFI 802.11a, b, g, n, ac, supporting 2.4/5 GHz Dual-Band
- BLUETOOTH 4.2
- Support for 11ac wireless standard and up to 433 Gbps data rate
* Actual data rate may vary depending on environment and equipment.
Expansion Slots 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
- AMD Ryzen
™
5000 Series Processors/AMD Ryzen
™
3000 Series Processors
support PCIe 4.0 x16 mode
- AMD Ryzen
™
5000 G-Series/4000 G-Series Processors support PCIe 3.0
x16 mode
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
4 x PCI Express x1 slots, integrated in the Chipset:
- Supporting PCIe 3.0 x1 mode
- 6 -
