- 4 -
B550 VISION D Motherboard Layout
Box Contents
5 B550 VISION D motherboard 5 One antenna
5 Motherboard driver disc 5 Four SATA cables
5 User's Manual 5 Two thermistor cables
5 Quick Installation Guide 5 One G Connector
5 OneRGBLEDstripextensioncable
* The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
CPU DRAM
VGA BOOT
USB 2.0 Hub
(Note 2)
KB_MS_USB
DP_HDMI
U32_LAN
U32_1
TYPEC_1
U32_2
TYPEC_2
QFLED QFLASH_PLUS
U32G2_LAN
ATX
DB_PORT
(Note 1)
AUDIO
DDR4_A1
DDR4_A2
DDR4_B1
DDR4_B2
ATX_12V
AMD B550
CLR_CMOS
M_BIOS
PCIEX8
PCIEX4
PCIEX16
SYS_FAN5_PUMPSYS_FAN4
SYS_FAN2
EC_TEMP1
CODEC
B550 VISION D
F_PANEL
F_USB1
SATA_DOM0
EC_TEMP2 SYS_FAN6_PUMP
F_USB2SYS_FAN3
USB 2.0 Hub
D_LED2
D_LED1
LED_C2
LED_C1
F_AUDIO
F_U32
SYS_FAN1
LED_CPU
M2_WIFI
COM
CPU_OPT
iTE
®
Super I/O
M2A_CPU
426080110
M2B_SB
426080110
30
SATA3
2
3
SATA3
0 1
BAT
Intel
®
GbE LAN
Intel
®
Thunderbolt
™
3
Controller
Intel
®
GbE LAN
TPM
Socket AM4
CPU_FAN
(Note 1) For debug code information, please refer to Chapter 3.
(Note 2) The chip is located on the back of the motherboard.
