7
E
N
DESCRIPTION
1. Auto off
2. Shot of steam button
3. Steam ON / Steam OFF
4. Cord
5. H
andle
6. S
pray trigger
7. T
hermostat control light
8. Water tank
9. Self clean button
10. Spray
11. High precision tip
12. Soleplate
13. F
illing inlet
14. Temperature control dial
15. R
ear Cover
Your iron has been designed to operate using untreated tap water. If in doubt, check with your
local water authority. However, if your water is very hard, you can mix 50% untreated tap water
with 50% distilled or demineralised water.
IMPORTANT Before doing anything else, remove the sticker on the side fig.1
Warning! Before using your iron with the steam function for the first time, we
recommend that you operate the steam in a horizontal position for a few moments,
away from your linen, i.e. press the Shot of Steam button a few times.
During the first few uses, a harmless odour and a small amount of smoke may be
noticeable.
This has no effect on the use of the iron and will cease quickly.
Upon the first use, you may notice small particles coming out of the soleplate. This
is parf of manufacturing process and is not harmful to you or your garments. It will
disappear after several uses. You may accelerate this by using the self cleaning
function
(fig.13a - 13b) and shaking the iron gently.
BEFORE USE
WHAT WATER MAY BE USED ?
Small in size , Steamforce combines power and performance thanks to the compact steam
generator built inside the iron. With unparalleled steam generation capacity reaching
220g/min and variable steam of up to 50g/min, Steamforce pushes up to 35% more
steam** into the fibres of your fabric. This extra steam at the heart of the fabric is the
secret of perfect ironing and long-lasting results.
T
he movement sensor is an intelligent system which temporarily stops steam being
r
eleased when the iron is not moving, even when it is placed horizontally. This function
e
liminates wasted steam while you are handling the clothes !
STEAMFORCE, CONCENTRATED INNOVATION…
IMPORTANT Heat concentrates the elements contained in water during evaporation.
The types of water listed below contain organic waste or mineral elements that can
cause spitting, brown staining or premature wear of the appliance:
water from tumble dryers, scented or softened water, water from refrigerators,
batteries or air conditioners, pure distilled or demineralised water or rain water should
not be used in your iron. Also do not use boiling, or bottled mineral water.
1 • Filling the water tank
• Before filling the water tank, unplug the iron fig.2.
• Set the temperature control dial fig.3 on position (Min.)
• Open the filling inlet fig.4. Fill in water up to the Max. mark. fig.5. Close the filling
inlet and return the iron to the horizontal position.
• You can plug in your iron fig.6
.
2 • Setting the temperature
Your iron is equipped with the Autosteam function, it automatically adjusts the
steam amount and the temperature based on the selected fabric for optimum
results.
Select the fabric to be ironed on the thermostat dial. For perfect results, an optimum
position for each fabric has been pre-defined. This position is marked on the dial.
You can also set your iron based on the international temperature measurements •,
••, •••. Ensure your thermostat dial is positioned on these settings.
When your iron reaches the required temperature, the thermostat indicator turns off
fig.7. You can start ironing.
USE
1103909919 DW9230 F1_110x220mm 22/04/13 15:16 Page7
