3. Technical Data

Gas Burners Rating

Rapid Burner (big) 3 kW (G20) - 2,8 kW (G30/31)

Auxiliary Burner (small) 1 kW

Category II 2H3+

Setting Natural Gas G 20 20 mbar

Gas connection G 1/2"

Electric Supply 230 V ~ 50 Hz

HOB RECESS DIMENSIONS

Length 270 mm.

Width 490 mm.

2. Cleaning and Maintenance

• Disconnect the appliance from the electrical

supply, before carrying out any cleaning or

manteinance work.

Wash the enamelled components with warm soapy

water. Never use abrasive cleaners

Frequently wash the "caps" and the "crowns" with hot

soapy water, carefully taking away any built-up of food.

Carefully wash the stainless steel components with

water, then wipe them dry with a soft cloth.

The pan supports are dishwasher proof.

If the marks are particularly difficult to remove, use

common non-abrasive cleaners or specific products.

Never use steel wool pads or acids.

In models provided with electric ignition, this feature is

obtained through a ceramic "candle" and a metal

electrode (Fig. 1 - lett. C). Keep these components well

clean, to avoid difficult lighting, and check that the burner

crown holes (Fig. 1 - lett. B) are not obstructed.

PERIODIC MAINTENANCE

Periodically ask your local Service Centre to check the

conditions of the gas supply pipe and the pressure

adjuster, if fitted.

To ensure the good operation of the hob and its safety

features, it is necessary that the taps are periodically

lubricated.

z The periodic lubrication of the taps must be

carried out by qualified personnel, which you

must refer to also in case of malfunctioning.

Fig. 2
