4
select standard mode, slide the MAM switch AK on the side of the
device downwards to position «1» and to select MAM mode, slide
this switch upwards to position «3».
MAM mode
In MAM mode, 3 measurements are automatically taken in succes-
sion and the result is then automatically analysed and displayed.
Because blood pressure constantly fluctuates, a result determined
in this way is more reliable than one produced by a single
measurement. AFIB detection is only activated in MAM mode.
• After pressing the ON/OFF button 1, the MAM-symbol BK
appears in the display.
•
The bottom, right hand section of the display shows a 1, 2 or 3 to
indicate which of the 3 measurements is currently being taken.
• There is a break of 15 seconds between the measurements
(15 seconds are adequate according to «Blood Pressure Moni-
toring, 2001, 6:145-147» for oscillometric instruments). A count
down indicates the remaining time.
• The individual results are not displayed. Your blood pressure
will only be displayed after all 3 measurements are taken.
• Do not remove the cuff between measurements.
• If one of the individual measurements was questionable, a
fourth one is automatically taken.
4. Taking a Blood Pressure Measurement using this
Device
Checklist for taking a reliable measurement
1. Avoid activity, eating or smoking immediately before the
measurement.
2. Sit down for at least 5 minutes before the measurement and relax.
3. Always measure on the same arm (normally left).
4. Remove close-fitting garments from the upper arm. To avoid
constriction, shirt sleeves should not be rolled up - they do not
interfere with the cuff if they are laid flat.
5. Always ensure that the correct cuff size is used (marking on the
cuff).
• Fit the cuff closely, but not too tight.
• Make sure that the cuff is positioned 2 cm above the elbow.
• The artery mark located on the cuff (ca. 3 cm long bar) must
lie over the artery which runs down the inner side of the arm.
• Support your arm so it is relaxed.
• Ensure that the cuff is at the same height as your heart.
6. Press the ON/OFF button 1 to start the measurement.
7. The cuff will now pump up automatically. Relax, do not move
and do not tense your arm muscles until the measurement
result is displayed. Breathe normally and do not talk.
8. When the correct pressure is reached, the pumping stops and the
pressure falls gradually. If the required pressure was not reached,
the device will automatically pump some more air into the cuff.
9. During the measurement, the heart symbol BT flashes in the
display every time a heartbeat is detected.
10.The result, comprising the systolic AM and the diastolic AN
blood pressure and the pulse rate AO is displayed. Note also the
explanations on further display symbols in this booklet.
11.When the device has finished measuring, remove the cuff.
12.Enter the result in the enclosed blood pressure pass and switch
off the device. (The monitor does switch off automatically after
approx. 1 min.).
How not to store a reading
As soon as the reading is displayed press and hold the ON/OFF
button 1 until «M» AS is flashing. Confirm to delete the reading by
pressing the M-button 2.
You can stop the measurement at any time by pressing the
ON/OFF button (e.g. if you feel uneasy or an unpleasant
pressure sensation).
5. Appearance of the Atrial Fibrillation Indicator for
early Detection (only in MAM mode)
This symbol
AP
indicates that an atrial fibrillation was detected
during the measurement. This device is able to detect atrial fibrilla-
tion (AFIB). If AFIB is present during blood pressure measurement,
the AFIB Indicator is displayed. In this case, the result may deviate
from your normal blood pressure. It is highly recommended to take
an additional measurement an hour later to increase the specificity
of the detection. In most cases, this is no cause for concern.
However, if the symbol appears on a regular basis (e.g. several
times a week with measurements taken daily) we advise you to visit
your doctor. Please, provide the following explanation:
