10
• Установка шпульки
1 Поместите шпульку 1 в шпуледержатель
2, нить должна отматываться так, как
показано на рисунке.
1 Шпулька
2 Шпуледержатель
3 Конец нити
2 Пропустите нить 4 в паз (А) в передней
части шпуледержателя. Проведите нить
влево между пружинами натяжения.
4 Зазор (А)
5 Пружина
3 Продолжайте осторожно вытягивать нить 6,
пока она не соскользнет в паз (В). Вытяните
около 15 см нити.
6 Паз (В)
4 Закройте крышку челночного отсека 8.
Сравните с подсказкой 9 на крышке 8,
правильно ли Вы заправили нить 7.
7 Нижняя нить
8 Крышка челночного отсека
9 Подсказка
10
z
x
c
v
e
w
• Inserting the bobbin
z Place the bobbin q in the bobbin holder w with the
thread running off as illustrated.
q Bobbin
w Bobbin holder
e End of thread
x Guide the thread into the notch (A) r on the front
side of the bobbin holder. Draw the thread to the
left, sliding it between the tension spring blades.
r
Notch (A)
t Spring
c Continue to draw the thread lightly until the
thread slips into notch (B)
y. Pull out about 15 cm
(6˝) of thread.
y Notch (B)
v Attach the hook cover plate i. Check the threading
by referring to the chart
o shown on the hook cover
plate
i.
u
Bobbin thread
i Hook cover plate
o Threading chart
q
r
t
y
u
i
o
11
q
w
e
r
y
t
c
z
x
v
b
z
x
c
v
b
Threading the Machine
• To set the needle thread
z Raise the presser foot with the presser foot lifter q.
Lead the thread from the spool and pass it
through the thread guide
w. Then draw it down
along the right slot.
q
Presser foot lifter
w Thread guide
x Then, down around the thread guide plate e.
e
Thread guide plate
c Raise the take-up lever to its highest position by
turning the handwheel towards you.
Firmly draw the thread from right to left over the
take-up lever
r and down into the take-up lever
eye.
r
Thread take-up lever
v Draw the thread down and slide the thread
behind the needle bar thread guide t from the left.
t
Needle bar thread guide
b Use the needle threader to thread the needle.
y
Needle
(see page 12).
