Janome Jem Gold 2 [17/25] Баланс натяжения верхней нити
![Janome Jem Gold 2 [17/25] Баланс натяжения верхней нити](/views2/1964262/page17/bg11.png)
16
Баланс натяжения верхней нити
• Выбор правильного натяжения
Для прямой строчки:
У идеальной прямой строчки нити переплетены
между двумя слоями ткани как показано на
рисунке.
Если посмотреть сверху и снизу на шов, все
стежки ровные и четкие, нет пропусков.
При регулировке натяжения верхней нити, чем
больше цифра, тем сильнее натяжение.
Результат зависит от:
*
структуры и толщины ткани
*
количества слоев ткани
*
типа строчки
1 Игольная нить (верхняя нить)
2 Шпульная нить (нижняя нить)
3 Изнаночная сторона ткани
4 Лицевая сторона
• Натяжение слишком сильное
1 Шпульная нить видна на лицевой стороне и
ткань стянута.
Поверните регулятор натяжения нити
(к меньшей цифре) и ослабьте натяжение
верхней нити.
5 Регулятор натяжения нити
• Натяжение слишком слабое
2 Игольная нить видна на изнаночной стороне
и ткань собирается.
Поверните регулятор натяжения (к большей
цифре) и увеличьте натяжение верхней
нити.
16
z
x
q
e
w
r
r
t
e
t
Balancing Needle Thread Tension
• Choose the correct tension
For straight stitch:
The ideal straight stitch will have threads locked between
the two layers of the fabric, as illustrated (magnified to
show detail).
If you look at the top and bottom of the seam, you will
notice that there are no gaps. Each stitch is smooth and
even.
Turn the dial to alter the needle thread tension. The higher
the number, the tighter the tension.
Results depend on:
* stiffness and thickness of the fabric
* number of fabric layers
* type of stitch
q
Needle thread (Top thread)
w Bobbin thread (Bottom thread)
e Wrong side of fabric
r Right side of fabric
• Tension is too tight
z The bobbin thread shows through on the right
side of the fabric and it feels bumpy.
Turn the thread tension dial upwards (to a smaller
number) to loosen the needle thread tension.
t Thread tension dial
• Tension is too loose
x The needle thread shows through on the wrong side
of the fabric and it feels bumpy.
Turn the thread tension dial downwards (to a
larger number) to tighten the needle thread tension.
17
r
q w e
q w e
q w e
Zigzag Stitching
Machine setting:
q Stitch selector:
w Presser foot: Zigzag foot A
e Thread tension dial: 2-5
The zigzag stitch is one of the most versatile stitches on
your machine. It can be a utility stitch for sewing on
buttons, buttonholing, hemming, overcasting, mending
and darning.
It can also be used to decorate with trims, appliques and
cutwork or as a decorative stitch.
Overcasting
Machine setting:
q Stitch selector:
w Presser foot: Overedge foot C
e Thread tension dial: 3-6
Overcasting is used on the seam allowance to prevent
fabrics from raveling at raw edges. It can be used to
finish a hem edge. Place the edge of the fabric next to the
black ridge of foot C.
r
Black ridge
Tricot Stitch
Machine setting:
q Stitch selector:
w Presser foot: Zigzag foot A
e Thread tension dial: 3-6
This stitch is used to finish the seam allowance on
synthetics and other fabrics that tend to pucker.
The stitch is excellent for darning and mending tears.
Place your fabric to allow a 1.6 cm (5/8˝) seam.
Trim the extra seam allowance after sewing as illustrated.
Note: Be careful not to cut the stitches.
SECTION IV UTILITY STITCHES
