4.4. Configuring the Network Switch
IGMP and Other Settings
Configuring the switch correctly will pass data more efficiently, allowing a better stream across the
network to each KVM over IP Extender device. The following settings will help optimize your network
traffic through a switch:
Enable IGMP Snooping on L2 switches
Enable IGMP Querier on the L3 switch
Enable Flow Control
Enable IGMP Fast-Leave on all switches where KVM over IP Extender units are directly connected
Enable Spanning Tree Protocol (STP) on all switches and enable Portfast exclusively on switch ports that
have KVM over IP Extender units connected
Pick an appropriate forwarding mode on all switches. Use Cut-through if available, or Store and Forward
The following table shows the recommended settings for various networking topologies:
Switch Feature
Single Switch Networking
Cascaded Switch Networking
Core Switch
Extended Switch
Green or energy-saving
Disable
Disable
Disable
Multicast forwarding / filtering
Enable
Enable
Enable
IGMP Snooping
Enable
Enable
Enable
IP Address of IGMP Querier
Must be assigned a valid value
N/A
IGMP Querier
Enable
Enable
Disable
IGMP Snooping fast leave
Enable
Disable
Enable
Note: Please refer to your switch’s user guide as different brands and models many have different names for these
features
