Aten KE8952 [15/17] Appendix
![Aten KE8952 [15/17] Appendix](/views2/1977448/page15/bgf.png)
5. Appendix
5.1 Recommended Network Switches
When using a point–to–multipoint or multipoint–to–multipoint (matrix mode) installation it is essential to
use a Gigabit network switch with IGMP functionality to experience the best performance. This allows for
more efficient throughput of bandwidth resources while supporting this type of setup.
The following table lists network switches that have passed ATEN's stress tests using the KE6900 series
extenders. Our tests streamed content over a network with a resolution of 1920 x 1200 @60Hz, 24bit
color depth at 60 frames per second.
ATEN
ES0152
ES0152P
Cisco
Catalyst 2960X
Catalyst 2960XR
Catalyst 3750
HP
Procurve 2920
H3C
S5120
Huawei
S5700
D-Link
DGS-1510
Netgear
M4300
Edgecore
ECS4120
Note: Please refer to the FAQ link below on how to select network switches and network switch information collected
by ATEN Customer Service Division, where the collected information includes customer's feedback from their actual
experience in using and installing the product(s).
https://eservice.aten.com/eServiceCx/Common/FAQ/view.do?id=6276
5.2 Example Switch Models and Capacity Calculations
When you are selecting a network switch suitable to be deployed with the KVM over IP Matrix System,
the most important values to check in advance are switching capacity and forwarding rate.
