5.4. PoE Considerations

Power over Ethernet (PoE) allows an Ethernet switch to provide both data and electrical power to a

network device through a single cable. The KE8952 / KE9952 model features PoE functionality, so the

transmitter and receiver units can receive power and communications over a single cable.

To avoid overall consumption exceeding the network switch’s power capacity, it is recommended that a

switch with enough capacity for 15.4W of power to every port is used.
