Aten KE8952 [16/17] Troubleshooting
![Aten KE8952 [16/17] Troubleshooting](/views2/1977448/page16/bg10.png)
Example Switch Models
Manufacturer
Model
Switching Capacity
Forwarding Rate
Huawei
S5700-28-C-HI
256 Gbps
96 Mpps
S5700-28-C-HI
256 Gbps
96 Mpps
S5710-10-BC-PWR-HI
1.024 Gbps
504 Mpps
D-Link
DGS-1510-28
92 Gbps
68.45 Mpps
DGS-1510-28X
128 Gbps
95.24 Mpps
DGS-1510-28P
92 Gbps
68.45 Mpps
DGS-1510-28XMP
128 Gbps
95.24 Mpps
DGS-1510-52
140 Gbps
104.15 Mpps
DGS-1510-52X
176 Gbps
130.95 Mpps
Switching Capacity – Total bandwidth of the switch * 2.
Forwarding Rate – Total bandwidth of the switch * 1.488.
Switch to Switch Bandwidth – Recommended bandwidth between switches depends on the total count of
receivers in the installation.
5.3 Troubleshooting
Problem: Monitors are flashing and mouse lags when streaming video.
I am using a Cisco Catalyst 2960 in my KVM over IP Matrix System installation (10 KVM over IP
Transmitters and 18 KVM over IP Receivers).
Remedy: Ensure that IGMP Querier is enabled. In addition to IGMP snooping for multicast installations,
IGMP Querier is also crucial. Use the following commands in Cisco 2960 CLI mode:
configure terminal
ip igmp snooping querier
end
show ip igmp snooping vlan 1
copy running-config startup-config
