4. Network Design

4.1. Planning Network Architecture

Build Strategies

For optimum performance, the KVM over IP Extenders require high amounts of data to be transferred

across a network; therefore we recommend the following strategies to setup the KVM over IP Extenders.

Using our suggestions will provide better performance and the highest video resolutions possible. Use

each of the keys to ensure the best transmission of data and the highest throughput possible. Prior to

setup we recommended laying out the plans for your KVM over IP Extender installation using the

following performance guide

Build a Network Diagram

To build an effective KVM over IP Extender installation, start by mapping out the layout. Create a diagram with

the KVM over IP Extenders, computers and routers along with how they will be connected across the network. It

also helps to write out how the devices will interact. Use the diagrams below as the framework as you decide what

devices to purchase and how to build the network effectively for the best data throughput.

Considerations:

 If possible, create a private network for the KVM over IP Extenders

 Use the same switch model throughout

 Use a flat cascaded layout

 Avoid a tree or pyramid structure

 Install network switches near each other

 Minimize the distance of connections

 Install KE Matrix Management Software (CCKM) computer and KVM over IP Extenders on the same

subnet

 Check the 5 following factors before installation:

Choose the Right Cable:

Always use Cat 5/6e Ethernet cable or higher installed by a professional between any two devices you are

installing. We recommend using ATEN Brand Ethernet cable to ensure the quality. It’s best when installing KVM

over IP Extenders to use brand new Ethernet cabling for each part of the installation to ensure the reliability of the

data being transmitted. This is a key to getting the best uninterrupted video resolution cross the network.

Determine the Distance:

Distance is an important factor when setting up networks, with a shorter distance and fewer hops through routers,

data can be transmitted more efficiently. So whenever possible decrease the distance and direct network traffic

effectively between subnets that communicate with each other to increase the data throughput.
