Chapter 1. Introduction
5
OSD tree structure makes finding and managing computers easy and
effortless
Console lock — enables the console drawer to remain securely locked
away when not in use
OSD port list automatically expands when new stations are added
Security — administrator / user password authentication for enhanced
security protection; Administrator access rights can be synchronized
between first and chained stations
OSD screen automatically adjusts to resolution changes
Two types of logout: manual and timed
Slideaway
TM
housing is slightly less than 1U with top and bottom
clearance for smooth operation in a 1U rack space
Optional rack mount kits available with easy installation options
DDC emulation — video settings of each computer are automatically
adjusted for optimal output for the connected monitors
Standard 105-key keyboard
Keyboard status restored when switching computers
Keyboard language supports English (US), English (UK), French,
German, German (Swiss), Greek, Hungarian, Italian, Japanese, Korean,
Russian, Spanish, Swedish, and Traditional Chinese
Requirements
Remote User Computers
Remote user computers (also referred to as client computers) are the ones the
users log into the switch with from remote locations over a network (see
Terminology, page xvi). The following equipment must be installed on these
computers:
For best results, we recommend computers with at least a Pentium III 1+
GHz processor, with their screen resolution set to 1024 x 768.
IE 8 or above web browser
Browsers must support TLS 1.2 encryption.
