Chapter 2. Hardware Setup
15
Single-Level Installation
To set up a single-level installation, where no additional switches are daisy
chained from the first unit, refer to the installation instructions and diagrams on
the following pages (the numbers in the diagrams correspond to the installation
step numbers).
1. Use a grounding wire to connect the switch’s grounding terminal to a
suitable grounded object.
2. Plug an Ethernet cable from the network into the LAN port.
3. (Optional) Use the console cable provided with the package to connect a
keyboard, monitor, and mouse to the console port. See Cabling Diagrams,
page 17.
Note: The length of the cable used shall not exceed 10 m.
4. For each of the computers you are installing, use a KVM cable set to
connect a KVM port to the computer's keyboard, video, and mouse ports.
See KVM Cable Installation Diagrams, page 17.
Note: The length of each KVM cable shall not exceed 10 m.
5. Plug one end of the power cord into the CL5708I / CL5716I’s power
socket and the other end into an AC power source.
6. Power on the CL5708I / CL5716I.
7. After the CL5708I / CL5716I is powered on, power on the connected
computers. See Powering Off and Restarting, page 24 for details.
