Appendix
225
IPv6 Stateless Autoconfiguration
If the KVM over IP switch’s network environment contains a device (such as
a router) that supports the IPv6 Stateless Autoconfiguration function, the KVM
over IP switch can obtain its prefix information from that device in order to
generate its IPv6 address. For example, 2001::74ff:fe6e:59.
As above, the address is displayed in the General list box of the Device
Management
→
Device Information page (see page 133).
Once you have determined what the IPv6 address is, you can use it when
logging in from a browser or the Win and Java Client AP programs.
For example:
If you are logging in from a browser, you would key in
http://[2001::74ff:fe6e:59]
for the URL bar.
If you are logging in with the AP program, you would key:
2001::74ff:fe6e:59
for the IP field of the Server panel (see Windows Client AP Login, page 57).
