VM6404H / VM6809H User Manual
106
The following tables show the possible values for the Switch Port command:
Note: 1. By default, input port 01 is tied to output port 01; input port 02 is tied
to output port 02; and so on until port 04 (i.e., o01 i01, o02 i02).
2. Each command string can be separated with a space.
3. The Port Number can be skipped, and the default value will be used.
4. The Group can be skipped, and the default value (normal; HDMI
audio output) will be used.
Command Description
sw Switch command
Input Command Description
i Input command
Port number Description
xx 01~04 or 01~08 port
Output Command Description
o Output command
Port number Description
yy 01~04 or 01~09 port
* All output ports
Group Description
normal default HDMI audio outputs
console audio Switch the audio to the stereo audio
output port of VM6809H.
Control Description
on Turn on the display
off Turn off the display
+ Next Port
- Previous Port
