eco PDU PE Low Profile Series User Manual
2
The low-profile series of ATEN PDUs have a circuit breaker alert that can
sound an alarm and send SNMP trap or e-mail alerts when a trip occurs. This
feature provides a faster response time to recover servers and other devices
when a circuit overload causes a loss of power.
With its advanced security features and ease of operation, the eco PDU is the
most convenient, most reliable, and most cost effective way to remotely
manage power access for multiple computer installations and allocate power
resources in the most efficient way possible.
Note: 1. Sensors are optional accessories. A sensor-enabled installation is
required to generate a more complete energy-efficient data and chart.
Higher sensor installation density is helpful to generate more accurate
data. See Optional Accessories, page 7, for further information.
2. eco PDUs are primarily designed for access via Intranet; extra
network security protection is suggested for Internet access usage.
