eco PDU PE Low Profile Series User Manual
20
PDU Placement
For safety reasons the eco PDU should not be installed with the power sockets
facing directly up or down, and thus should only be installed with the power
sockets facing out from a vertical position as shown below:
Right
Wrong
Floor
Floor
