Chapter 1. Introduction
9
Note: Holes for ATEN Lok-U-Plug cable holders are located around the
sockets. See Securing the Cables, page 23, for further information.
No. Item Description
1 Power Cord This is the power cord that connects the unit to an
AC power source via NEMA L6-30P (208V)
(PE6324LB / PE6324LJ) or IEC 60309 32A
(PE6324LG) plug.
2 Circuit Breakers (Bank 1
and Bank 2)
2 x 16A Slim Breakers. As a safety measure, if
there is an overcurrent situation regarding the
device’s power, the circuit breakers will trip. Push
the switch back to recover normal operation.
3 Power Outlets* 3 x IEC 320 C19
4 21 x IEC 320 C13
5 Sensor Ports External sensors plug into these two RJ-11 ports.
6 LAN Port and LEDs The cable that connects the eco PDU to the LAN
plugs in here. The Link and LAN LEDs are built
into the LAN port:
Link: Lights GREEN to indicate that a connection
via the eco PDU's RJ-45 Ethernet port has been
established. Flashes to indicate data is being
transmitted.
LAN: Lights ORANGE to indicate 10 Mbps data
transmission speed. The LED lights GREEN to
indicate 100 Mbps data transmission speed.
7 Readout Section and
Reset Switch
Details of this section are provided on page 16.
8 Outlet Status LEDs These 24 LEDs indicate the outlet power status.
Lights ORANGE for powered on. Off for powered
off.
