Aten PE6324L [19/86] Cable holders are optional accessories for added safety use aten lok u plug cable holders to secure the cables from your attached devices in place on the eco pdu unit use only the aten lok u plug cable holders that have been specifically designed to work with the eco pdu using any other kind of cable securing device could be highly dangerous
![Aten PE6324L [19/86] Cable holders are optional accessories for added safety use aten lok u plug cable holders to secure the cables from your attached devices in place on the eco pdu unit use only the aten lok u plug cable holders that have been specifically designed to work with the eco pdu using any other kind of cable securing device could be highly dangerous](/views2/1978015/page19/bg13.png)
Chapter 1. Introduction
7
Optional Accessories
Sensors
Sensors are optional accessories. You can use the eco PDU unit without
sensors. However, if you want to have complete energy management of an
instrumented data center with the use of the eco PDU, you would need to use
eco DC, a management web GUI, and install 4 sensors for each of the racks to
generate a complete energy-efficient data and chart. Higher sensor installation
density is helpful to generate more accurate data. 24/40 -port models have 2
sensor ports. In this case, Sensor 1 needs to be installed at the intake of the rack
and sensor 2 needs to be placed at the exhaust of IT equipment of the rack. A
sensor-enabled installation is required to generate a more complete energy-
efficient data and chart. Higher sensor installation density is helpful to generate
more accurate data. Available sensors are show in the table, below:
Cable Holders
Cable holders are optional accessories. For added safety, use ATEN Lok-U-
Plug cable holders to secure the cables from your attached devices in place on
the eco PDU unit. Use only the ATEN Lok-U-Plug cable holders that have
been specifically designed to work with the eco PDU. Using any other kind of
cable securing device could be highly dangerous.
Sensor Part Number
Temperature EA1140
Temperature / Humidity EA1240
Differential Pressure / Temperature EA1340
Part Number Description
2X-EA07 Lok-U-Plug Cable Holder (10 pcs)
2X-EA08 Lok-U-Plug Installation Tool (4 pcs)
