Appendix
71
PE5340SLB / PE5340SLJ / PE5340SLG
Function PE5340SLB PE5340SLJ PE5340SLG
Power Outlets Direct 40
Connectors Power Cord 1 x NEMA L6-30P 1 x IEC 60309
32A
Power Outlets Total: 40 x IEC320 C13
Bank1: Outlet 1–20; 20 x C13
Bank2: Outlet 21–40; 20 x C13
Sensor 2 x RJ-11
LAN 1 x RJ-45 Female (Silver) + LEDs (Orange/Green)
LEDs PDU / Phase 1 digit 7-segment (Orange)
PDU/Phase / Bank / IP 3 (Green)
PDU/Phase / Bank / IP 3-digit 7-segment (Orange)
Power 1 (Blue)
LAN 10/100M 1 (Orange / Green)
Link 1 (Green)
Sensor 2 (Green)
Switches Reset 1 x Semi-recessed Pushbutton
Power 2 x 16A Slim Breaker
Button 1 x Pushbutton
I/P Rating 100–240V~; 50–60Hz;
30A (Max), 24A (UL de-rated)
100–240V~; 50–
60Hz; 32A
Power Capacity 6240 VA (Max); 4992 VA (UL de-rated) 7360 VA (Max)
O/P Rating Per Outlet 100–240V~; 50–60Hz;
C13: 15A (Max), 12A (UL de-rated)
100–240V~; 50–
60Hz;
C13: 10A (Max)
Per Bank 100–240V~; 50–60Hz;
15A (Max), 12A (UL de-rated)
100–240V~; 50–
60Hz;
16A, 15A (TUV
de-rated)
Total 100–240V~; 50–60Hz;
30A (Max), 24A (UL de-rated)
100–240V~; 50–
60Hz;
32A (Max), 30A
(TUV de-rated)
Environment Operating Temperature
0–50
o
C 0–50
o
C 0–40
o
C
Storage Temperature
-20–60
o
C
Humidity 0–80% RH Non-condensing
Physical
Properties
Housing Metal
Weight 4.5 kg 4.5 kg 4.5 kg
Dimensions (L x W x H) 135.9 x 6.6 x 4.4 cm
