1
Chapter 1
Introduction
Overview
ATEN has developed a new generation of green energy power distribution
units (PDUs) to effectively increase the efficiency of data center power usage.
The ATEN PE6324LB / PE6324LG / PE6324LJ / PE6324LJA / PE5340SLB /
PE5340SLG / PE5340SLJ / PE5340SLJA eco PDUs are low profile intelligent
PDUs that contain 24 or 40 AC outlets and are available in various IEC or
NEMA socket configurations. The low profile series has a smaller input region
on the PDU to provide more installation space for data centers.
They provide secure, centralized, intelligent, power management (power on,
off, cycle) of data center IT equipment (servers, storage systems, KVM
switches, network devices, serial data devices, etc.), as well as the ability to
monitor the center's health environment via sensors*. The basic characteristics
of each model are shown in the table on page 3.
ATEN eco PDUs offer remote power control combined with real-time power
measurement - allowing you to control and monitor the power status of devices
attached to the PDUs, either at the PDU device or outlet level, from practically
any location via a TCP/IP connection.
The power status of each outlet can be set individually, allowing users to switch
each device On/Off. The eco PDU also offers comprehensive power analysis
reports which can separate departments and locations, providing precise
measurements of current, voltage, power and watt-hour in a real-time display.
Installation and operation is fast and easy: plugging cables into their
appropriate ports and user-friendly browser-based configuration and
management is all that is entailed. Since the eco PDU firmware is upgradeable
over the Net, you can stay current with the latest functionality improvements
simply by downloading updates from our website as they become available.
ATEN eco PDU supports any 3rd party V1, V2, V3 SNMP Manager Software
and ATEN eco DC (Energy & DCIM Management Web GUI). eco DC
provides you with an easy method for managing multiple devices, offering an
intuitive and user-friendly Graphical User Interface that allows you to
configure a PDU device and monitor power status of the equipment connected
to it.
