S2989G-24TX Operation Manual
Chapter 8 Debugging and Diagnosis Configuration
8-26
3. Configure mirror destination port
Command
Explanation
Global Mode
monitor session <session> destination
interface <interface-number>
no monitor session <session>
destination interface
<interface-number>
To configure mirror destination interface;
The no command deletes the mirror
destination port.
4. Configure reflector port
Command
Explanation
Global Mode
monitor session <session>
reflector-port <interface-number>
no monitor session <session>
reflector-port
To configure the interface to reflector
port; The no command deletes the
reflector port.
5. Configure remote VLAN of mirror group
Command
Explanation
Global Mode
monitor session <session>
remote vlan <vid>
no monitor session <session> remote
vlan
To configure remote VLAN of mirror
group, the no command deletes the
remote VLAN of mirror group.
8.7.3
Typical Examples of RSPAN
Before RSPAN is invented, network administrators had to connect their PCs directly
to the switches, in order to check the statistics of the network.
However, with the help of RSPAN, the network administrators can configure and
supervise the switches remotely, which brings more efficiency. The figure below shows a
sample application of RSPAN.
