Installation
High Performance 10-20k UPS
12
2. Installation
The system should be installed and wired only by qualified electricians in accordance with
applicable safety regulations.
NOTICE:UPS operation in sustained temperature outside the range of 15-25
C (59
-77
F) reduces
battery life.
2.1 Unpacking and Inspection
1) Unpack the packaging and check the package contents. The shipping package contains:
● 1 UPS
● 1 user manual
2) Inspect the appearance of the UPS to see if there is any damage during transportation. Do not turn
on the unit and notify the carrier and dealer immediately if there is any damage or lacking of
some parts.
2.2 Connect Input/Output Power
1. Notes for installation
1) The UPS must be installed in a location with good ventilation, far away from water,
inflammable gas and corrosive agents.
2) Ensure the air vents on the front and rear of the UPS are not blocked. Allow at least 0.5m of
space on each side.
3) Condensation to water drops may occur if the UPS is unpacked in a very low temperature
environment. In this case it is necessary to wait until the UPS is fully dried inside out before
proceeding installation and use. Otherwise there are hazards of electric shock.
2. Installation
Installation and wiring must be performed in accordance with the local electric code and the following
instructions by professional personnel.
For safety, please cut off the mains power switch before installation. Open the battery breaker for long
backup time model (“L” model).
1) Open the terminal block cover located on the rear panel of the UPS, please refer to the
appearance diagram.
2) For10k(L) UPS, it is recommended to select the UL1015 8AWG(10mm
2
) wire or other
insulated wire which complies with AWG Standard for the UPS input and output wirings.
3) For20k(L) UPS, it is recommended to select the UL1015 4AWG(25mm
2
) wire or other
insulated wire which complies with AWG Standard for the UPS input and output wirings.
NOTICE:Do not use the wall receptacle as the input power source for the UPS, as its rated current is
less than the UPS’s maximum input current. Otherwise the receptacle may be burned and destroyed. For
the long backup time modes, make sure that the capacity of batteries is larger than 5*charger current
to avoid over charging. If not, please confirm the charge current and set the charge current according to
battery capacity.
