6. CARE AND MAINTENANCE – DISPOSAL
TRANSPORT – STORING
During transportation ensure the rigging components are not stressed or damaged by mechanical forces. Use suitable
transport cases. We recommend the use of the RCF HDL30 touring kart for this purpose.
Due to their surface treatment the rigging components are temporarily protected against moisture. However, ensure the
components are in a dry state while stored or during transportation and use.
SAFETY GUIDE LINES – HDL30-A KART
Do not stack more than four HDL30-A on one Kart.
Exercise extreme caution when moving stacks of four cabinets with the kart to avoid tipping.
Do not move stacks in the front-to-back direction of the HDL30 (long side); always move stacks sideways to avoid
tipping.
