RCF HDL 30-A (13000511) 72033594 [30/32] Specifications
![RCF HDL 30-A (13000511) 72033594 [30/32] Specifications](/views2/1989715/page30/bg1e.png)
HDL30-A
Frequency Response 50 Hz - 20 kHz
Max Spl 137 dB
Horizontal Coverage Angle 100°
Vertical Coverage Angle 10°
Compression Driver 1.4”, 4.0”v.c.
Woofer 2x10”, 2.5”v.c.
INPUTS
Input Connector XLR, RDNet Ethercon
Output Connector XLR, RDNet Ethercon
Input Sensitivity + 4 dBu
PROCESSOR
Crossover Frequency 680 Hz
Protections thermal, RMS
Limiter soft limiter
Controls
Preset, RDNet Bypass
AMPLIFIER
Total Power 2200 W Peak
High Frequencies 600 W Peak
Low Frequencies 1600 W Peak
Cooling Forced
Connections Powercon in-out
PHYSICAL SPECIFICATIONS
Height 293 mm (11.54”)
Width 705 mm (27.76”)
Depth 502 mm (19.78”)
Weight 25.0 Kg (55.11lbs)
Cabinet PP composite
Hardware Array fittings
Handles 2 side
SPECIFICATIONS
