Owner’s Manual
15
Owner’s Manual
14. Tape Out
TheseunbalancedRCAconnectionstapthemain
mixoutputtomakesimultaneousrecordingandPA
workmoreconvenient.Connectthesetoyourrecorder’s
inputs.(Seealsomainmix[29]onpage19.)
MonoOut:Ifyouwanttofeedamonosignaltoyour
tapedeckorotherdevice,simplyuseanRCAY-cordto
combinetheseoutputs.Donotattemptthiswithany
otheroutputsonthe802VLZ4.
15. Aux Send
ThisisaTRS1⁄4"balanced/unbalancedoutput,
commonlyusedtofeedstagemonitors(withauxset
topre)oranexternaleffectsprocessor(withauxset
topost).
Theauxsend[28]knobstapaportionofeach
channel'ssignaltoprovideanoutputhere,allowing
youtosetupanicestagemonitormix,ortosetupan
externaleffectfromdifferentchannels.Seetheaux
senddetailsonpage18.
16. 1/4" Main Outs
These1⁄4"TRSbalanced/unbalancedoutputsfeed
themainmixoutintothewaitingworld.Youmayfeed
theampliersorpoweredspeakersthisway,orthrough
theXLRmainouts[17].
Tousetheseoutputstodrivebalancedinputs,
connect1⁄4"TRS(Tip–Ring–Sleeve)phoneplugs
likethis:
Tip=+(hot)
Ring=–(cold)
Sleeve=Ground
FormostmusicrecordingandPAapplications,
unbalancedlinesarene.Todriveunbalancedinputs,
connect1⁄4"TS(Tip–Sleeve)phoneplugslikethis:
Tip=+(hot)
Sleeve=Ground
17. XLR Main Outs
Usethesetosendthemainmixoutintotheline-level
balancedinputsofyouramplierorpoweredspeakers.
Theselow-impedanceoutputsarefullybalanced,
andthisoutputis6dBhotterthanotheroutputs.
18. XLR Main Out Level Switch
Engagingthisswitchreducesthelevelofthebalanced
XLRmainoutputs,soyoucanfeedthemicrophone
inputof,say,anothermixer.(Youcansafelyconnectthe
XLRoutputsintoaninputthatprovides48Vphantom
power.)
19. Power Connection
Thisiswhereyouplugintheconnectorfromthe
ACadaptersuppliedwithyourmixer.
OnlyusetheACadapterthatcamewithyour
mixer,orafactory-authorizedpowersupply.
20. Power Switch
Pressthetopofthisrockerswitchinwardstoturnon
themixer.ThepowerLED[39]onthetopsurfaceof
themixerwillglowwithhappiness,oratleastitwillif
youhavetheACadapterpluggedintoasuitableliveAC
mainssupply.
Pressthebottomofthisswitchtoputthemixerinto
standbymode.Itwillnotfunction,butthecircuitsarestill
live.Toremovepower,eitherturnoffthemainssupply,
orunplugthepowercordfromthemixerandthemains
supply.
Asageneralguide,youshouldturnonyourmixer
rst,beforethepoweramplierorpoweredspeakers,
andturnitofflast.Thiswillreducethepossibilities
ofanyturn-on,orturn-offthumpsinyourspeakers.
20 19
