ADJ Products, LLC - www.adj.com - Vizi Hex Wash7 Instruction Manual Page 31
ADJ Products, LLC - www.adj.com - Vizi Hex Wash7 Instruction Manual Page 30
2. Press the LEFT or RIGHT buttons until “Status” is displayed, press
ENTER.
3. Press LEFT or RIGHT buttons, until “Feedback” is displayed, and
press ENTER.
4. Either “O” or “On” will be displayed, use the LEFT or RIGHT but-
tons to toggle between.
5. Press ENTER to conrm your selection or press MODE to exit.
Movement Speed - With this function you can set the pan and tilt
movement speed.
1. Press the MODE button to access the main menu. Press the UP or
DOWN buttons so that “Function” is highlighted, then press ENTER.
2. Press the LEFT or RIGHT buttons until “Status” is displayed, press
ENTER.
3. Press LEFT or RIGHT buttons, until “Move. Speed” is displayed,
and press ENTER.
4. Either “Speed 1”, “Speed 2”, “Speed 3” or “Speed 4” will be dis-
played, use the LEFT or RIGHT buttons to toggle between.
5. Press ENTER to conrm your selection or press MODE to exit.
Stand By - With this function the LEDs and step motors will power
o if there is no DMX signal within 15 mins (factory defualt). Once it
receives a DMX signal, the xture will reset itself.
1. Press the MODE button to access the main menu. Press the UP or
DOWN buttons so that “Function” is highlighted, then press ENTER.
2. Press the LEFT or RIGHT buttons until “Status” is displayed, press
ENTER.
3. Press LEFT or RIGHT buttons, until “Stand By” is displayed, and
press ENTER.
4. The current stand by setting will be displayed, use the LEFT or
RIGHT buttons to adjust the hibernation period between 01M-99M or
Vizi Hex Wash7 System Menu
Vizi Hex Wash7 System Menu
“O”.
5. Press ENTER to conrm your selection or press MODE to exit.
Fixture ID
Password - With this function you can enter the RDM password so
that you can access and change the RDM ID number.
1. Press the MODE button to access the main menu. Press the UP or
DOWN buttons so that “Function” is highlighted, then press ENTER.
2. Press the LEFT or RIGHT buttons until “Fixture ID” is displayed,
press ENTER.
3. Press the LEFT or RIGHT buttons until “ServicePIN” is displayed,
press ENTER.
4. The “Password” is 050.
5. Press ENTER or press MODE to exit.
RDM PID - RDM stands for “Remote Device Management”. This
feature lets you control every aspect of your xture remotely from an
RDM controller. Manual settings like adjusting the DMX address are
no longer needed. This is especially useful when the unit is installed
in a remote area.
In this submenu you can see the units RDM ID number and adjust it
as well.
1. Press the MODE button to access the main menu. Press the UP or
DOWN buttons so that “Function” is highlighted, then press ENTER.
2. Press the LEFT or RIGHT buttons until “Fixture ID” is displayed,
press ENTER.
3. Press LEFT or RIGHT until “RDM PID” is displayed, and press
ENTER.
4. “XXXXXX” will be displayed. “XXXXXX” represents the units current
RDM ID.
5. Press ENTER or press MODE to exit.
Fan Set
