Unpacking: Thank you for purchasing the Vizi Hex Wash7 by ADJ
Products, LLC. Every Vizi Hex Wash7 has been thoroughly tested and
has been shipped in perfect operating condition. Carefully check the
shipping carton for damage that may have occurred during shipping.
If the carton appears to be damaged, carefully inspect your xture for
any damage and be sure all equipment necessary to operate the unit
has arrived intact. In the event damage has been found or parts are
missing, please contact our toll free customer support number for fur-
ther instructions. Please do not return this unit to your dealer without
contacting customer support rst.
Introduction: The Vizi Hex Wash7 is a DMX intelligent, moving head,
wash fixture. The Vizi Hex Wash7 has 3 DMX channel modes; 19 chan-
nels, 21 channels, or 27 channels. The fixture has two different operat-
ing modes; auto program or DMX control. The Vizi Hex Wash7 can be
used as a stand alone unit or in a master/slave configuration. For best
results use fog or special effects smoke to enhance the beams projec-
tions.
Customer Support: ADJ Products, LLC provides a toll free cus-
tomer support line, to provide help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.adj.com for any comments or
suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2610
E-mail: support@americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Warning! This may cause severe eye damage. Avoid looking directly
into the light source at all times!
Vizi Hex Wash7 General Information
ADJ Products, LLC - www.adj.com - Vizi Hex Wash7 Instruction Manual Page 3ADJ Products, LLC - www.adj.com - Vizi Hex Wash7 Instruction Manual Page 2
Table of Contents
Unpacking......................................................................3
Introduction....................................................................3
Customer Support......................................................................3
Safety Precautions......................................................................4
Features.........................................................................5
Handling Precautions..................................................................5
Registration......................................................................5
Mounting.........................................................................7
DMX Set-Up...........................................................................9-11
DMX Control..............................................................................12
DMX Traits............................................................................13-21
Color Macro Chart................................................................22-24
System Menu............................................................................25
Operation...............................................................................42
Photometric Chart................................................................44-45
Dimmer Curve Chart.................................................................46
Fuse Replacement....................................................................46
Cleaning..................................................................................47
Trouble Shooting.......................................................................47
Warranty.........................................................................48
Specifications....................................................................50
