ADJ Products, LLC - www.adj.com - Vizi Hex Wash7 Instruction Manual Page 50
Model: Vizi Hex Wash7
Voltage: 100~240V, 50/60Hz
LEDs: 7 x 15W RGBWA+UV 6-in-1 LEDs
LED Life: 50,000 Hrs.
Beam Angle: 7 - 58 Degrees
Power Consumption: 137W
PowerCon Daisy Chain: 5 Fixtures Max. (110V
11 Fixtures Max. (240V)
Dimensions: 11.75”(L) x 8”(W) x 15.75”(H)
300 x 200 x 400mm
Weight: 19 Lbs. / 8.5 kgs.
Colors: RGBWA+UV
Fuse: 5A (120V) 3A (240V)
Duty Cycle: None
DMX: 3 DMX Channel Modes: 19 Channels,
21 Channels, or 27 Channels
Working Position: Any Safe, Secure Position
Warranty: 2 Year (730 days)
Vizi Hex Wash7 Specifications
ADJ Products, LLC
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-725-6100
Web: www.adj.com / E-mail: info@americandj.com
A.D.J. Supply Europe B.V.
Junostraat 2
6468 EW Kerkrade
The Netherlands
service@adjgroup.eu / www.adj.eu
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Auto Sensing Voltage: This xture contains a automatic volt-
age switch, which will auto sense the voltage when it is plugged
into the power source.
