Vizi Hex Wash7 System Menu
Time. Info (Time information is always represented in hours)
Current - This will allow you to check units current running time since
power has been activated.
1. Press the MODE button to access the main menu. Press the UP
or DOWN buttons so that “Information” is highlighted, then press
ENTER.
2. Press the LEFT or RIGHT buttons until “Time. Info” is displayed,
press ENTER.
3. Press LEFT or RIGHT buttons, until “Current” is displayed, and
press ENTER.
4. “XXXX” will now be displayed. “XXXX” represents the current run-
ning time.
5. Press ENTER or press MODE to exit.
Total Time - This will allow you to check units total running time.
1. Press the MODE button to access the main menu. Press the UP
or DOWN buttons so that “Information” is highlighted, then press
ENTER.
2. Press the LEFT or RIGHT buttons until “Time. Info” is displayed,
press ENTER.
3. Press LEFT or RIGHT buttons, until “Total Time” is displayed, and
press ENTER.
4. “XXXX” will now be displayed. “XXXX” represents the total run-
ning time.
5. Press ENTER or press MODE to exit.
Last Clear - This will show you the last time the time was cleared.
1. Press the MODE button to access the main menu. Press the UP
or DOWN buttons so that “Information” is highlighted, then press
ENTER.
2. Press the LEFT or RIGHT buttons until “Time. Info” is displayed,
Vizi Hex Wash7 System Menu
3. Either Slave 1, Slave 2, or Slave 3 will be displayed. Use the LEFT
or RIGHT buttons to nd your desired setting and press ENTER, or
the press MODE button to exit.
Auto. Pro - This function allows the internal programs to run in either
stand-alone or master/slave mode. In “Master” mode the xture
will send DMX data to other xtures connect via the DMX chain. In
“Alone” mode the xture will operate as a single xture. The program
for this mode is selected in the “Select program” section of
the control menu. You can set the number of steps under “Edit pro-
gram”. You can edit the individual scenes under “Edit scenes”. With
this function, you can run the individual scenes either automatically,
i.e. with the adjusted Step-Time.
1. Access the main menu, and press the UP or DOWN buttons so
that “Function” is highlighted, then press ENTER.
2. Press the LEFT or RIGHT buttons until “Auto. Pro” is displayed,
and press ENTER.
3. Either “Master” or “Alone” will be displayed. Use the LEFT or
RIGHT buttons to nd your desired setting.
4. Press ENTER to to make your selection, or press MODE button to
exit.
DFSE
DFSE - With this function you can restore the factory settings.
1. Access the main menu, and press the UP or DOWN buttons so
that “Function” is highlighted, then press ENTER.
2. Press the LEFT or RIGHT buttons so that “DFSE” is highlighted,
then press ENTER.
3. Either “O” or “On” will be displayed, use the LEFT or RIGHT but-
tons to toggle between. Selecting “On” will restore the factory set-
tings.
4. Press ENTER to conrm your selection or press MODE to exit.
INFORMATION
