ADJ Products, LLC - www.adj.com - Crazy Pocket 8 User Manual Page 20 ADJ Products, LLC - www.adj.com - Crazy Pocket 8 User Manual Page 21
Crazy Pocket 8 9 Channel Mode
Channel Value Function
1 0 - 255
PAN
2 0 - 255 TILT HEAD 1
3 0 - 255 TILT HEAD 2
4 SHUTTER/STROBE
0 - 7 OPEN
8 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 OPEN
190 - 231 FAST OPEN - SLOW CLOSE
232 - 239 OPEN
240 - 247 SOUND ACTIVE STROBE
248 - 255 OPEN
5 0 - 255 MASTER DIMMER 0% - 100%
6 CHASES
0 - 7 BLACKOUT
8 - 22 CHASE 1
23 - 37 CHASE 2
38 - 52 CHASE 3
53 - 67 CHASE 4
68 - 82 CHASE 5
83 - 97 CHASE 6
98 - 112 CHASE 7
113 - 127 CHASE 8
128 - 142 CHASE 9
143 - 157 CHASE 10
158 - 172 CHASE 11
173 - 187 CHASE 12
188 - 202 CHASE 13
203 - 217 CHASE 14
218 - 232 CHASE 15
233 - 247 CHASE 16
248 - 255 FULL ON
Crazy Pocket 8 9 Channel Mode
Channel Value Function
7 CHASE SPEED
0 - 255
SLOW - FAST
8 PAN/TILT 1/ TILT 2 SPEED
0 - 255 FAST - SLOW
9 RESET/BLACKOUT
0 - 69 NOTHING
70 - 79 BLACKOUT W/ PAN/TILT MOVEMENT
80 - 89 RESET TILT 1
90 - 99 RESET TILT 2
100 - 109 RESET PAN
110 - 199 NOTHING
200 - 209 RESET ALL
210 - 255 NOTHING
