ADJ Products, LLC - www.adj.com - Crazy Pocket 8 User Manual Page 23ADJ Products, LLC - www.adj.com - Crazy Pocket 8 User Manual Page 22
Crazy Pocket 8 17 Channel Mode
Channel Value Function
13 CHASES
173 - 187 CHASE 12
188 - 202 CHASE 13
203 - 217 CHASE 14
218 - 232 CHASE 15
233 - 247 CHASE 16
248 - 255 FULL ON
14 CHASE SPEED
0 - 255 SLOW - FAST
15 PAN/TILT 1/ TILT 2 SPEED
0 - 255 FAST - SLOW
16 RESET/BLACKOUT
0 - 69 NOTHING
70 - 79 BLACKOUT W/ PAN/TILT MOVEMENT
80 - 89 RESET TILT 1
90 - 99 RESET TILT 2
100 - 109 RESET PAN
110 - 199 NOTHING
200 - 209 RESET ALL
210 - 255 NOTHING
17 DIMMER MODE
0 - 20 STANDARD
21 - 40 STAGE
41 - 60 TV
61 - 80 ARCHITECTURAL
81 - 100 THEATRE
101 - 255 DEFAULT DIMMER SETTING
Crazy Pocket 8 17 Channel Mode
Channel Value Function
1 0 - 255 PAN
2 0 - 255 PAN FINE
3 0 - 255 TILT HEAD 1
4 0 - 255 TILT HEAD 1 FINE
5 0 - 255 TILT HEAD 2
6 0 - 255 TILT HEAD 2 FINE
7 0 - 255 RED 0% - 100%
8 0 - 255 GREEN 0% - 100%
9 0 - 255 BLUE 0% - 100%
10 0 - 255 AMBER 0% - 100%
11 SHUTTER/STROBE
0 - 7 OPEN
8 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 OPEN
190 - 231 FAST OPEN - SLOW CLOSE
232 - 239 OPEN
240 - 247 SOUND ACTIVE STROBE
248 - 255 OPEN
12 0 - 255 MASTER DIMMER 0% - 100%
13 CHASES
0 - 7 BLACKOUT
8 - 22 CHASE 1
23 - 37 CHASE 2
38 - 52 CHASE 3
53 - 67 CHASE 4
68 - 82 CHASE 5
83 - 97 CHASE 6
98 - 112 CHASE 7
113 - 127 CHASE 8
128 - 142 CHASE 9
143 - 157 CHASE 10
158 - 172 CHASE 11
