ADJ Products, LLC - www.adj.com - Boom Box FX3 Instruction Manual Page 18 ADJ Products, LLC - www.adj.com - Boom Box FX3 Instruction Manual Page 19
Boom Box FX3 3 Channel Mode
Channel Value Function
1 SHOW MODE
0 - 69 NO FUNCTION
70 - 79 SHOW 1
80 - 89 SHOW 2
90 - 99 SHOW 3
100 - 109 SHOW 4
110 - 119 SHOW 5
120 - 129 SHOW 6
130 - 139 SHOW 7
140 - 209 SHOW 8
210 - 249 SHOW 9
250 - 255 SHOW 0
2 SHOW SPEED
0 - 255 SHOW SPEED SLOW - FAST
3 SPECIAL FUNCTIONS
0 - 139 NO FUNCTION
140 - 209 RESET ALL
210 - 249 NO FUNCTION
250 - 255 SOUND ACTIVE
Boom Box FX3 52 Channel Mode
Channel Value Function
1 MATRIX RED LED 1
0 - 255 0% - 100%
2 MATRIX GREEN LED 1
0 - 255 0% - 100%
3 MATRIX BLUE LED 1
0 - 255 0% - 100%
4 MATRIX RED LED 2
0 - 255 0% - 100%
5 MATRIX GREEN LED 2
0 - 255 0% - 100%
6 MATRIX BLUE LED 2
0 - 255 0% - 100%
7 MATRIX RED LED 3
0 - 255 0% - 100%
8 MATRIX GREEN LED 3
0 - 255 0% - 100%
9 MATRIX BLUE LED 3
0 - 255 0% - 100%
10 MATRIX RED LED 4
0 - 255 0% - 100%
11 MATRIX GREEN LED 4
0 - 255 0% - 100%
12 MATRIX BLUE LED 4
0 - 255 0% - 100%
13 MATRIX RED LED 5
0 - 255 0% - 100%
14 MATRIX GREEN LED 5
0 - 255 0% - 100%
15 MATRIX BLUE LED 5
0 - 255 0% - 100%
16 MATRIX RED LED 6
0 - 255 0% - 100%
17 MATRIX GREEN LED 6
0 - 255 0% - 100%
18 MATRIX BLUE LED 6
0 - 255 0% - 100%
