ADJ Products, LLC - www.adj.com - Boom Box FX3 Instruction Manual Page 10
ADJ Products, LLC - www.adj.com - Boom Box FX3 Instruction Manual Page 11
System Menu: When making adjustments press ENTER to
conrm your setup then press and hold the MENU button
for at least 3 seconds. To exit without making any adjust-
ments press the MENU button. The display will lock after 30
seconds, press the MENU button for 3 seconds to unlock.
ADDR - DMX Address Setting.
1. Press the either the MENU, UP, or DOWN buttons until “ADDR” is
displayed, press ENTER.
2. The current address will now be displayed and ashing. Press the
UP or DOWN buttons to nd your desired address. Press ENTER to
set your desired DMX address.
CHND - This will let select your desired DMX channel
mode.
1. Press the MENU button until “CHND” is displayed, press ENTER.
The current DMX channel mode will be displayed
2. Press the UP or DOWN buttons to nd your desired DMX channel
mode and press ENTER to conm and exit.
SLND - This will let you set unit as a master or slave in a
master/slave conguration.
1. Press the MENU button until “SLND” is displayed, press ENTER.
Either “MAST”, “SL 1”, or “SL 2” will be displayed.
2. Press the UP or DOWN buttons until your desired setting is dis-
played, press ENTER to conm.
NOTE: In a Master/Slave conguration you can set one xture to
Master and then set the next xture to “SL 2”, the xtures will now
have contrast movement to each other.
Boom Box FX3 System Menu
Boom Box FX3 System Menu
SHND - Show modes 0-9 (Factory programs).
1. Press the MENU button until “SHND” is displayed, press ENTER.
2. “Sh X” will now be displayed, “X” representing a number between
0-6. Shows 1-6 are factory programs, while show “0” is random mode.
Use the UP or DOWN buttons to nd your desired show.
3. When you have found your desired show press ENTER, then press
and hold the MENU button for at least 3 seconds to activate. After
you have set your desired show, it can be changed at any time using
the UP or DOWN buttons.
SOUN - Sound Active mode.
1. Press the MENU button until “SOUN” is displayed, press ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or
DOWN buttons to select “ON” to activate sound active mode, or
“OFF” to deactivate sound active mode.
3. Press ENTER to conrm.
SENS - In this mode you can adjust the sound sensitiv-
ity.
1. Press the MENU button until “SENS” is displayed, press ENTER.
2. A number between 0-100 will be displayed. Press the UP or DOWN
buttons to adjust the sound sensitivity. 0 being the least sensitive,
and 100 being the most sensitive.
3. When you have found your desired setting press ENTER to conrm.
