ADJ Products, LLC - www.adj.com - Boom Box FX3 Instruction Manual Page 12 ADJ Products, LLC - www.adj.com - Boom Box FX3 Instruction Manual Page 13
Boom Box FX3 System Menu
DNST - This mode can be used as a precaution mode,
that in case the DMX signal is lost, interrupted, or power is
lost, the operating mode chosen in the setup is the running
mode the xture will go into when the DMX signal is lost. You
can also set this as the operating mode you would like the
unit to return to when power is applied.
1. Press the MENU button until “DNST” is displayed, and either
“MASL”, “BLND”, or “LAST” will be displayed beneath.
2. Press ENTER and the bottom choice will begin to ash. Use the UP
or DOWN buttons to choose an operating mode you would like the unit
to start up in when power is applied or the DMX signal is lost.
• LAST - If the DMX signal is lost the xture will stay in the last DMX
setting. If power is applied and this mode is set, the unit will automati-
cally go into the last DMX set up.
• MASL (Master Slave) - If the DMX signal is lost or power is applied,
the unit will automatically go into Master Slave mode and run a built-in
show.
• BLAC (Blackout) - If the DMX signal is lost or interrupted, the unit will
automatically go into stand by mode.
3. Press ENTER to conrm your desired set up.
DISP - This function will reverse the display 180º.
1. Press the MENU button until “DISP” is displayed, press ENTER.
2. Press ENTER to “ip” the display. Press ENTER to “ip” it again.
Press ENTER when you have made your desired setup.
Boom Box FX3 System Menu
LED - With this function you can have the LED display
turn off after 10 seconds.
1. Press the MENU button until “LED” is displayed, press ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or
DOWN buttons to select “ON” to keep the LED display on at all
times, or “OFF” to switch to have the LED display switch o after 10
seconds.
TEST - This function will run a self test program.
1. Press the MENU button until “TEST” is displayed, press ENTER.
2. The xture will now run a self test.
FHRS - With this function you can display the running
time of the unit.
1. Press the MENU button until “FHRS” is displayed, press ENTER.
2. The running time of the xture will now be displayed. Press MENU
to exit.
VER - Use this function to display the Software version of
the unit.
1. Press the either the MENU button until “VER” is displayed, press
ENTER.
2. The display will show the software version.
RSET - This function will reset the unit.
1. Press the MENU button until “RSET” is displayed. Press the
ENTER button and the unit will reset itself.
