ADJ Products, LLC - www.adj.com - Boom Box FX3 Instruction Manual Page 22 ADJ Products, LLC - www.adj.com - Boom Box FX3 Instruction Manual Page 23
Boom Box FX3 52 Channel Mode
Channel Value Function
45 3RD RING GREEN LED
0 - 255 0% - 100%
46 3RD RING BLUE LED
0 - 255 0% - 100%
47 4TH RING RED LED
0 - 255 0% - 100%
48 4TH RING GREEN LED
0 - 255 0% - 100%
49 4TH RING BLUE LED
0 - 255 0% - 100%
50 SHOW MODE
0 - 69 NO FUNCTION
70 - 79 SHOW 1
80 - 89 SHOW 2
90 - 99 SHOW 3
100 - 109 SHOW 4
110 - 119 SHOW 5
120 - 129 SHOW 6
130 - 139 SHOW 7
140 - 209 SHOW 8
210 - 249 SHOW 9
250 - 255 SHOW 0
51 SHOW SPEED
0 - 255 SHOW SPEED SLOW - FAST
52 SPECIAL FUNCTIONS
0 - 139 NO FUNCTION
140 - 209 RESET ALL
210 - 249 NO FUNCTION
250 - 255 SOUND ACTIVE
Boom Box FX3 Fuse Replacement
Boom Box FX3 Cleaning
Boom Box FX3 Trouble Shooting
Trouble Shooting: Listed below are a few common problems that
you may encounter, with solutions.
No light output from the unit;
1. Be sure the external fuse has not blown. The fuse is located on
the rear panel of the unit.
2. Be sure the fuse holder is completely and properly seated.
Unit does not respond to sound;
1. Low frequencies (bass) should cause the unit to react to sound.
Tapping on the microphone, quiet or high pitched sounds may
not activate the unit.
2. Check the sound sensitivity level.
Fixture Cleaning: Due to fog residue, smoke, and dust cleaning
the internal and external optical lenses and mirror should be carried
out periodically to optimize light output. Cleaning frequency depends
on the environment in which the fixture operates (I.e. smoke, fog
residue, dust, dew). In heavy club use we recommend cleaning on a
monthly basis. Periodic cleaning will ensure longevity, and crisp out-
put.
1. Use normal glass cleaner and a soft cloth to wipe down the out-
side casing.
2. Use a brush to wipe down the cooling vents and fan grill.
3. Clean the external optics and mirror with glass cleaner and a soft
cloth every 20 days.
4. Clean the internal optics with glass cleaner and a soft cloth every
30-60 days.
5. Always be sure to dry all parts completely before plugging the unit
back in.
Disconnect the unit from its power source. Remove the power cord
from the unit. Once the cord has been removed, the fuse holder is
located next to the I.E.C. power connection. Use a phillips head screw-
driver to remove the fuse holder. Remove the fuse located inside the
fuse holder and replace with the new fuse. Install the fuse holder and
new fuse and secure it.
