ADJ Products, LLC - www.adj.com - Fog Fury 3000 Instruction Manual Page 6 ADJ Products, LLC - www.adj.com - Fog Fury 3000 Instruction Manual Page 7

Fog Fury 3000 Description

The new Fog Fury 3000 fog machine features a fog juice level sensor.

When the fog juice level is low, a LED below the reservoir will flash. When

the fog juice level reaches a lower level, a bult-in sensor inside the res-

ervoir will automatically shut off the pump. This will greatly expand the

life of the pump. The new Fog Fury 3000 fog machine included a revolu-

tionary new heating element that has been specially designed to prevent

excessive particle build up that can cause premature fogger failure. The

fog machine also includes a remote control, that may be removed for

periods on non-use.

Fog Fury 3000 Set-Up

1. Open the shipping carton and carefully remove the unit from the

shipping carton.

2. Be sure to remove all the packing material especially around the

nozzle.

3. Set the fog machine on a flat dry surface. Locate the included

bracket from the package and install it using the supplied hard-

ware to the side casing. Note: The bracket is an optional accesso-

ry and may not be used if desired, however if you intend to sus-

pend the unit from truss the bracket must be used.

4. Fill the fog fluid reservoir with ADJ brand fog juice. Place the feed-

er tube with the filter deep inside the reservoir and tighten the cap.

5. Firmly attach the remote control unit to the rear remote control

socket on the unit.

6. Plug the unit in to a matching power supply. At this time the fluid

reservoir will glow red, this indicates that the unit is heating up.

Wait about eight minutes for the fogger to reach normal operating

temperature. When it has reached the temperature, the reservoir

will glow blue.

7. Either press the remote button to emit fog or use the manual but-

ton on the rear of the unit to emit fog. See the next page for timer

control and DMX control.

8. Follow the operating instructions on the next page for proper

operation.

NOTE: If the LED under the reservoir begins to flash, this indicates that

fog juice fluid is low.

Fog Fury 3000 Layout
