Appendix: Specifications
A•1
AppenDiX: SpecificAtionS
System
NOTES
Working Range
100M/300Ft Line of sight, actual range depends on
interference, reection and RF signal
absorption high & low
Audio Freq Response
10 Hz( -0.5 dB) to 20 kHz (-2.5 db)
THD%
0.03% typical
Dynamic Range
>115 dBA V70
>120 dBA V70L
system total audio in to audio out
- no compander
Operating Temperature
Range
1°C to 50°C battery characteristics may limit this
range
Transmitter Audio Polarity
positive pressure on mic dia-
phragm produces positive voltage
on pin 2 of XLR output and on Tip
of 1/4 output
RF Channel
2.4GHz ISM band
System Latency Total
<4ms Audio in to audio out
