About The XD-V70 System
1•2
Supplied System Components
• half rack receiver (RX212)
• power supply; 9Vdc/500mA, input – 90 – 240 Vac (DC-1G)
• ½ wave rubber ducky antennas, pair (model RDrac)
• Rackmount kit (includes short and long rack ears, mounting screws and dovetail
key)
• Front mount antenna kit (including BNC connectors and antenna cables)
• 50 ohm BNC termination plugs (pair)
Handheld TX
• Handheld transmitter (THH12)
• Mic clip
• 2 x AA alkaline batteries
• Rugged zippered carry case
Beltpack System
• Beltpack transmitter (TBP12)
• LM4-T cardioid lav mic w/ clip and windscreen
• 2 x AA alkaline batteries
• Rugged zippered carry case
