About The XD-V70 System
1•1
About the XD-V70 SyStem
• 24 bit digital converters
• Up to 120 dBA dynamic range, compander free
• DCL™ and PDP™ technologies eliminate audio interference and minimize dropouts
• Full bandwidth 10 – 20kHz frequency response
• 12 user selectable channels (for simultaneous use) always available, no
intermodulation issues. No scanning for channels is required
• Quick setup- no gain, pads, squelch or level adjustments necessary
• “Future Proof” 2.4GHz ISM band operation prevents concerns from DTV/
DSO/700MHz channel assignments and White Space Devices and avoids
competition from high power transmitters such as commercial TV, mobile phone
and public safety
• Real-time LCD indicators display critical performance indication including:
operating channel, RF status, Link Status, Battery Life and Diversity Mode
• 2 x AA Alkaline batteries provide 8 hour operation on “high” power, 10 hours on
“low” power
