Appendix: Specifications
A•2
V70 Handheld Transmitter
NOTES
Audio Input (max)
3.6Vpp ~3% THD (clipping)
Gain Range
N/A patent pending auto gain compensation
circuitry optimizes A/D converter bit rate
RF Output
10 mW (high power)
3.3 mW (low power)
Dimensions (overall)
107mm x 40mm x 40mm
Weight
11 oz. (w/o batteries)
Housing
metal body, polycarbonate
battery cover
Battery Life
8 hours (high power)
10 hours (low power) -alkaline
Power
2 x “AA” Alkaline
V70 Beltpack Transmitter
NOTES
Audio Input Level (max)
6.5Vpp ~3% THD (clipping)
Input Z
1.3M ohms
Gain Range
N/A patent pending auto gain compensation
circuitry optimizes A/D converter bit rate
Supplied Bias Voltage
5 VDC Pin 2 of TA4 Connector
RF Output
10 mW (high power)
3.3 mW (low power)
Dimensions (overall)
107 mm x 70mm x 30mm
Weight
6.5 oz (w/o batteries)
Housing
metal body
Battery Life
8 hours (high power)
10 hours (low power) -alkaline
Power
2 x “AA” Alkaline
