XD-V70 Receiver

2•2

3. Environmental Filter

The Environment ﬁlter combines a downward expander with a dynamic high pass ﬁlter.

It should be used to minimize handling noise and stage vibrations that are not intended

to be a part of your program material. When the microphone falls below a ﬁxed threshold

the ﬁlter backs down the overall level by about 6 dB while simultaneously rolling off

frequencies below 200 Hz. “Norm” is the default setting for musical performance. The

ﬁlter may be bypassed entirely by selecting “off”, or may be increased by selecting “Talk”

which is more appropriate for speech applications of the system.

Front Panel LED Ladders

The XD-V70 receiver features an array of LED ladders so that critical performance

elements can be viewed when you are too far away to read the LCD screen.

Audio

This row shows the relative strength of the audio output. The more lights the stronger

the signal at the output connector. This ladder will be off when the system is muted. It

is normal in operation for these LEDs to move around between a single LED to all ﬁve

being on.

Mute

A red LED will signal that the mute switch has been engaged on the transmitter and

output to the rear panel output jacks will be turned off.

Battery

Each LED lit represents approximately 1.5 hours of remaining battery life when green. The

bottom LED will light red when approximately two hours of operating time or less remain,

and will ﬂash red when approximately .5 hour remains. For more detailed information on

remaining batter life, please read the LCD screens on the transmitter or receiver.
