2. PRODUCT SPECIFICATIONS
2-3) Electric Parts Specification
RB37A**9** RB37A**5** RB37A**0** RB37A**1**(CIS)
Compon nents for Freezer
Refrigerant R-600a
Freezing Capacity
4-Star
Compressor
Model NC4MVA1ALP/TT1 NC4MVA1ALP/TT1 MSV4A1AL1R/TT1 MSV4A1AL1R/TT2
Starting type BLDC BLDC BLDC BLDC
Oil Charge 200±10 200±10 200±10 200±10
Evaporator Freezer Split Fin Type
Condenser
(Convection Type)
forced type convection type convection type convection type
Dryer Molecular sieve XH-9
Capillary Tube
OD1.8xID0.85xL3900 CU - - -
OD2.05xID0.75xL4500 CU OD1.8xID0.75xL4000 OD1.8xID0.75xL4000 OD1.8xID0.75xL4000
Electric Components
Defrost Heater
Conducting
at F Defros
230V / 150W
Thermal-Fuse for preventing
overheating of Refrigerator
Defrost-Heater
AC250V, 10A, 109~110℃
Over-load
Relay
Model
4TM445PHBYY-82
Temp. ON 125℃ ± 5
Temp. OFF 69℃ ± 9
Rated Voltage 200 - 240V ~ 50Hz, 220V ~ 60Hz
Motor
F ROOM 12035GE-12M-YT-F1
R ROOM
12035GE-12M-YT-F1
-
-
-
C ROOM G1538S12D1-SS-TTL
Damper
R ROOM
Damper
- NSBA001TF1, DC12V, 60mA
Lamp LED Type DC12V,65*10*1.6T, FR4.3PKG
Door Switch Reed switch, DC 200V, 1.5A
